EKKO EK50LP LPG Forklift – 10,000 lbs Capacity | 185″ Lift Height

\n

The EKKO EK50LP Liquid Propane 4-Wheel Forklift is built for demanding material handling, warehousing, and distribution applications. Designed with durable construction, Tier 4 EPA compliance, and powered by a Kubota engine, this forklift delivers reliable performance and efficient operation in industrial environments.

\n

The forklift features a multifunction instrument panel for monitoring safe and efficient operation, along with an operator-focused compartment designed for comfort and visibility. A non-slip entrance step, wider access area, additional leg room, and adjustable steering column help reduce operator fatigue during extended use.

\n

Its integral heavy-duty chassis enhances driver protection, while the steer axle pivots up to 80 degrees for a tighter turning radius and improved maneuverability. Hydraulic controls provide smooth handling and lifting performance.

\n

Features

\n

\n
• 10,000 lbs load capacity
\n
• 185″ lift height
\n
• LPG (Liquid Propane) powered
\n
• Tier 4 EPA compliant Kubota engine
\n
• Multifunction instrument panel
\n
• Adjustable steering column
\n
• Non-slip entrance step
\n
• Wider operator access and leg room
\n
• Excellent operator visibility
\n
• Heavy-duty chassis for driver protection
\n
• Hydraulic controls
\n
• Steer axle pivots to 80 degrees for tighter turning radius
\n

\n

Specifications

\n

\n
• Model: EK50LP
\n
• Drive Type: LPG
\n
• Operation Type: Propane
\n
• Load Capacity: 10,000 lbs
\n
• Load Center: 24 in.
\n
• Lift Height: 185 in.
\n
• Wheelbase: 61.8 in.
\n
• Service Weight: 16,250 lbs
\n
• Tire Type: Cushion Tires
\n
• Traction Pin Height: 11.2 in.
\n
• Service Brake: Hydraulic Foot Pedal
\n
• Parking Brake: Mechanical Hand Lever
\n
• Overall Width: 55.9 in.
\n
• Overall Length with Forks: 157 in.
\n
• Overall Length without Forks: 109 in.
\n
• Minimum Ground Clearance at Mast: 4.3 in.
\n
• Maximum Travel Speed (Loaded/Unloaded): 10.5 / 11.2 MPH
\n
• Mast Overall Height: 91.9 in.
\n
• Free Lifting Height: 44.3 in.
\n
• Backrest Height from Fork Surface: 47.6 in.
\n
• Fork Size: 48 × 5.9 × 1.97 in.
\n
• Engine Model: Kubota WG3800
\n
• Engine Power: 63.2 HP
\n

\n

Available now at stoolby.com.
