Stratus Commercial Grade On-Ground or In-Ground Mount Low Profile Full Rise Scissor Car Lift

Name: Stratus Commercial Grade On-Ground or In-Ground Mount Low Profile Full Rise Scissor Car Lift
Brand: TryIlluminate
SKU: 83842
Price: 3679.0 USD
Availability: InStock

$3,679.00

FAST & FREE Shipping Worldwide

30-Day Money Back Guarantee

Buy Now, Pay Later With Klarna

This low-profile double scissor lift comes with On-Ground surface mount or In-Ground flush mount design, it is pneumatic safety lock release with overload protection, easy to operate and maintain. Full size scissor car lift is suitable to hold 10,000 lbs. or less, ideally for inspection, repair and maintenance of various types of vehicles.

Product Features

Commercial grade open center full rise low profile scissor lift
2 in 1 design – On-Ground surface mount or In-ground flush mount (see detailed foundation plan)
Pneumatic safety lock release
Durable cylinders with anti-surge valves
Overload protection
Alloy solid steel X structure, good rust resistance and not easy to deform
Ramp can be used as platform extension suitable for different length of chassis
Wear-resisting bearings
9 lock position, each lock position is 2 1/8″ (55mm) apart.
8 pcs rubber pads included, 4 of each 1 1/2″ & 4″
Low profile design, minimum height is only 4 5/16″
24V low voltage control system
Platforms can be extended for long vehicles
Self-lubricated bushing and bearing
Proofed by dynamic test with 115% of rated capacity and static test with 150% rated capacity
Powder coating finish: Granite Gray (RAL 7026) + Rein orange (RAL 2004)

Product Specifications

Model	UT10000
Capacity	10,000
Lifting Time	~90SEC
Max Height	72 1/16″ (1830 MM)
Min Height	4 5/16″ (110 MM)
Runway Length without Ramps	60 1/4″ (1530 MM)
Runway Length with Ramps	84 1/4″ (2140 MM)
Overall Width	85 13/16″ (2180 MM)
Runway Width	26 3/16″ (665 MM)
Between Runway	33 7/16″ (850 MM)
Motor	4 HP, 220V, 60 HZ, 1ph
Oil	AW32 or AW46
Breaker	30A
Platform Weight	2,006 LBS
Platform Dimension	69″ L * 29″ W * 19″ H
Control Panel Weight	198 LBS
Control Panel Dimension	44″ L * 18″ W * 22″ H

PDF guide

We've gone paperless! To help the environment & to protect our customers during these times, we don't ship our products with paper manuals that get thrown away 30 seconds after anyway, below we have a comprehensive PDF & Video guide on how to install/use all of our products correctly so it's crystal clear for you!

Inside this thorough PDF guide you can find FAQs to most of your concerns please take a look inside and use the contents page to find what you're specifically looking for.

Here's PDF guide you can access at anytime 💡

Click Here for the New & Updated PDF

Click Here to watch our video guide
